Advantages
1.Simplicity of design and rugged construction have made cone crushers ideal for crushing operations.
2.The lubrication unit is interlocked with the main motor for additional safety as a standard equipment.
3.Arib liner is provided inside the bottom section of the frame to help protect it from wear.
4.The spring-loaded releases system allows and uncrushable material to pass through without causing and damage.
5.There are generally four types of Series Cone Crushers: the WLC Standard or the coarse type, the WLM fine or the medium type, the WLF Short Head type & WLCF Super Fine Type. All the four types are designed for secondary or tertiary crushing purpose both in stationary.
| Hydraulic clearance body cavity |
|
Had iron release |
| Hydraulic Qing Wei cavity is broken cone machine power standard configuration, placed in the body by a group Recommended clearance from the cavity for the 75mm. The use of fully automated structure-ching of a cavity at the same time the role of the fuel tank to over-protection of iron release |
|
Li Wei, general-purpose machine broken cone structure of the "spring-loaded" than the protection of iron release. Structure using a set of automatic pressure storage tanks can be adjusted to facilitate the release of force iron, iron can be released in time too. |
| Technical parameters |
|
Model
|
Max Feed Size
(MM)
|
Min Discharge opening
(mm)
|
Main Motor Power
(kw)
|
Close Discharge Size(mm) Capacity(TPH)
|
|
6
|
10
|
13
|
16
|
19
|
22
|
25
|
38
|
51
|
64
|
|
WLCC1000
|
160
|
13
|
90-110
|
|
|
70
|
90
|
125
|
135
|
160
|
215
|
|
|
|
WLCM1000
|
115
|
10
|
90-110
|
|
55
|
65
|
70
|
90
|
120
|
135
|
|
|
|
|
WLCF1000
|
80
|
8
|
90-110
|
47
|
50
|
60
|
67
|
90
|
|
|
|
|
|
|
WLCC1160
|
180
|
13
|
110-132
|
|
|
105
|
120
|
135
|
160
|
180
|
2200
|
|
|
|
WLCM1160
|
130
|
10
|
110-132
|
|
72
|
92
|
105
|
135
|
150
|
170
|
|
|
|
|
WLCF1160
|
90
|
10
|
110-132
|
|
70
|
90
|
100
|
125
|
|
|
|
|
|
|
WLCC1300
|
200
|
16
|
132-160
|
|
|
|
135
|
160
|
180
|
200
|
290
|
350
|
|
|
WLCM1300
|
150
|
13
|
132-160
|
|
|
105
|
125
|
135
|
160
|
180
|
|
|
|
|
WLCF1300
|
102
|
10
|
132-160
|
|
80
|
105
|
135
|
140
|
|
|
|
|
|
|
WLCC1380
|
215
|
19
|
185-220
|
|
|
|
|
180
|
200
|
230
|
310
|
400
|
|
|
WLCM1380
|
160
|
16
|
185-220
|
|
|
|
130
|
160
|
180
|
200
|
|
|
|
|
WLCF1380
|
115
|
13
|
185-220
|
|
|
135
|
170
|
190
|
210
|
|
|
|
|
|
WLCC1500
|
235
|
22
|
185-220
|
|
|
|
|
210
|
245
|
290
|
380
|
480
|
530
|
|
WLCM1500
|
175
|
19
|
185-220
|
|
|
|
|
195
|
234
|
250
|
295
|
|
|
|
WLCF1500
|
130
|
13
|
185-220
|
|
|
170
|
190
|
220
|
230
|
250
|
|
|
|
|
WLCC1650
|
267
|
22
|
250-300
|
|
|
|
|
|
300
|
350
|
475
|
600
|
660
|
|
WLCM1650
|
203
|
16
|
250-300
|
|
|
|
210
|
250
|
280
|
300
|
|
|
|
|
WLCF1650
|
140
|
13
|
250-300
|
|
170
|
205
|
240
|
310
|
|
|
|
